TCG one-component thermal conductive gel series products are a kind of high-performance silicone thermal conductive gel, which is made of silica gel and high-performance ceramic powder. It has the advantages of high compression, low thermal resistance, and good fit. It can be used for dispensing operation with high efficiency. It can work for a long time at -40~200℃.

Features

Thermal conductivity 2-8W/mk

Soft, with excellent compressibility and excellent fit

Excellent heat dissipation effect and good temperature resistance

Applicable to automation equipment, efficient and fast

Typical application

Automotive Electronics

 Power equipment

Wireless equipment and modules

Intelligent terminal equipment

Packaging Information

Packing specifications: 30CC, 50CC, 100CC/pc, or canned customized

Instructions

Manual type: When using, you need to unscrew the nozzle cover, connect the dispensing head, and then clamp the hose to the bayonet of the glue gun, apply glue hard, and finally dispense the evenly mixed thermally conductive glue to the heating position according to the heat dissipation structure design. 

Automatic type: It is mainly used on the glue dispenser. After unscrewing the nozzle cover, put the rubber tube into the glue dispenser cartridge, and then screw it to the glue dispenser. Mainly refer to the use requirements of the glue dispenser.
